This module belongs to the Bently Nevada 3500 series and supports programming through 3500 Rack Configuration Software. Each channel can be configured with different functions as needed and run in pairs.

It receives seismic transducer input, generates vibration measurement values after signal conditioning, and compares them with user set alarm points for mechanical protection and operation status monitoring.

This type of module is particularly suitable for reciprocating compressor systems because it can effectively monitor crank cases and cross-head vibrations, thereby helping to identify abnormal vibrations, impacts, and potential faults.

Manufacturer Bently Nevada

Model 3500/70M 176449-09

Type Recip Impulse Velocity Monitor

Number of channels: 4 channels

Input signal: Seismic transducers

Programmable functionality Impulse Acceleration, Acceleration 2, Recip Velocity, Low-Frequency Recip Velocity

Power consumption 8.5 watts typical

Input impedance 25 k Ω

Maximum switch current 5 A

Maximum switch voltage 30 Vdc

Weight 0.82 kg

Size 9.50 in x 0.96 in x 9.52 in

Applying Recreating Compressors, Crackcase, and Crosshead Vibration Monitoring

Q1: What equipment is the 3500/70M 176449-09 mainly used for?

Mainly used for reciprocating compressors, monitoring crank cases and cross-head vibration.

Q2: What measurement functions does it support?

Supports Impulse Acceleration, Acceleration 2, Recip Velocity, and Low Frequency Recip Velocity.

Q3: How many channels does this module have?

It is a 4-channel monitoring module, and the channels can be configured in pairs.
