This module receives input signals from proximity probes or magnetic pickups, converts them into digital Keyphasor signals, and accurately indicates the alignment time between the Keyphasor mark on the shaft and the sensor.

The 3500 system can accept up to 4 Keyphasor signals (normal configuration) or 8 (paired configuration), and this module is backward compatible with existing Keyphasor modules, supporting multiple event/conversion signal generation and on-site firmware upgrades.

Mainly used for mechanical protection and condition monitoring of rotating equipment such as steam turbines, compressors, pumps, and generators, helping to identify faults such as imbalance, misalignment, and shaft cracks.

Manufacturer Bently Nevada

Product Code125792-01

Model 3500/25

Type Enhanced Keyphasor Module (half height 2-channel)

Bently Nevada 3500 Monitoring System

Input signal proximity probes, magnetic pickups

Output Digital Keyphasor signals

Power consumption 3.2 Watts typical

Dimensions 119.9 x 24.4 x 256.5 mm

Weight 0.34 kg

Working temperature -40 ° C to+85 ° C

Application of Rotating Machinery Protection

Q1: What are the main functions of 3500/25 125792-01?

Provide Keyphasor signals for precise measurement of speed and 1X vibration phase, supporting mechanical fault diagnosis.

Q2: What types of input signals can this module receive?

Receive signals from proximity probes and magnetic pickups.

Q3: How many Keyphasor signals can the 3500 system support at most?

Normal configuration supports 4, paired configuration supports 8 Keyphasor signals.

Q4: Is this module backward compatible?

Fully backward compatible with existing Keyphasor modules, with identical form, adaptation, and functionality.
