Bently Nevada 146031-01 is a transient data interface I/O module in the 3500/22M system, used to capture real-time vibration data of rotating equipment and transmit it to diagnostic software. It bridges the monitoring system with System 1 software and supports static and dynamic waveform analysis.

The module supports 10Base-T/100Base TX Ethernet, with dimensions of 241.3 x 24.4 x 99.1 mm and a weight of 0.2 kg.

Working temperature -30 ° C to+65 ° C, humidity 95% non condensing, installed in Slot 1 of 3500 rack, supporting automatic MDIX and LED status indication.

Type Transient Data Interface I/O Module

Network 10/100Base TX Ethernet

Working temperature -30 to+65 ° C

Storage temperature -40 to+85 ° C

Dimensions (HxWxD) 241.3 x 24.4 x 99.1 mm

Weight 0.2 kg

Suitable for transient vibration monitoring during startup/shutdown of equipment such as steam turbines and gas compressors, used in conjunction with M-series monitors.

Deploy in power plants and offshore platforms, support high sampling rates (up to 10kHz), and detect bearing wear or misalignment issues early.

BENLTY Bently Nevada 3500/46M Hydraulic Monitor

The semiconductor industry has some of the most demanding applications that combine extremely high accuracy and precision with high throughput. Semiconductor processing can be divided into two parts - "front-end" and "back-end".

The term backend refers to the process of cutting a chip into individual chips and all subsequent processes; For example, testing, assembly, and packaging. The goal of online packaging inspection equipment is to provide high-precision 100% analysis while maintaining high throughput.

System Requirements

The challenge of keeping up with packaging innovation has sharply increased. The rapid development towards higher density and smaller size is pushing the limits of the visual system.

To address these issues, the company is seeking a complete high-performance system that can reliably capture images to perform high-speed, high-precision online detection. Meanwhile, the customer wishes to reduce installation/maintenance work.

System Description

When equipment manufacturers design advanced precision machining machines, choosing the right components determines their level of success. For this project, the motion control card, image acquisition card, and camera greatly affect the overall productivity and accuracy of the system. Therefore, Advantech has proposed an intelligent GigE visual frame grabber, a DSP based multi axis motion control card, and a compact modular system for direct integration in space limited machines to achieve high-precision and high productivity IC packaging inspection.

This solution uses industrial grade computers combined with PCIE-1174 and a four channel intelligent GigE visual frame grabber (including dedicated field programmable gate arrays (FPGAs)) to reconstruct images, which are then transmitted in real-time to the host PC through DMA (direct memory access). This frees up the host's processor and ensures that there is no frame or packet loss during the image acquisition process. To further assist with installation and maintenance, this series also includes the use of PoE (Power over Ethernet) and Ad Hoc protocols, which, like DHCP, do not require a specific IP address, allowing system integrators (SIs) to simply plug in the camera for use.
