Bently Nevada128229-01 is designed specifically for 3500/42M Proximitors ®/ The I/O module designed by Seismic Monitor has an internal terminal block that receives 1-4 Bently Nevada displacement sensor signals. The standard I/O input impedance is 10k Ω, and the effective impedance under TMR configuration is 50k Ω, which complies with the API 670 mechanical protection standard.

Dual sensor support: Proximitor ® Proximity probe+seismic sensor, continuously comparing monitoring parameters with alarm set points

Signal processing: -10Vdc to+10Vdc input, driving alarm relay output

Communication interface: Communicate with the 3500 rack high-speed backplane to transmit critical machine information to operation/maintenance personnel

Flexible installation: full-size module, can be installed in any slot on the right side of RIM, supports multi module expansion

Brand Bently Nevada

Model 128229-01 (3500/42M)

Type Proximitor/Seismic I/O Module

Input signal -10Vdc~+10Vdc

Power consumption 10.5W

Working temperature -30 ° C to+65 ° C

Size 241.3 × 24.4 × 99.1 mm (height × width × depth)

Weight 0.39-0.91kg (source slightly different)

Ethernet 100Base FX fiber optic

Compatible System 3500 Rack Series

A complete protection system is composed of 3500/20 RIM, 3500/05 rack, 3500/60 temperature module, 3500/93 display, etc., dedicated to monitoring high-speed rotating equipment such as steam turbines, gas turbines, compressors, etc.

Protection of key equipment in power plants and petrochemical plants, providing earthquake activity monitoring and displacement measurement, preventing catastrophic failures, and supporting proactive maintenance strategies.

Pressure controllers can be used for neutral or corrosive gas and liquid media. The set value range is adjustable, with an adjustment range of 0.02~42Mpa. The switching difference is not adjustable. The pressure controller includes a wide range and many varieties, including differential pressure controller, explosion-proof pressure switch, explosion-proof differential pressure switch, pressure transmitter, differential pressure transmitter, wind pressure switch, and wind pressure transmitter.

The function of a pressure controller is to detect, display, alarm, and control signal output to ensure the normal operation of the system. It collects and processes data through a high-speed MCU and has built-in precision sensors for compensation. It is a high-precision device that detects pressure and liquid level signals, achieves pressure and liquid level monitoring and control. Widely used in automation systems for measuring gas and liquid pressure in chemical, mechanical, hydrological, electrical, environmental, and other fields. Due to its convenient and flexible adjustment, as well as simple installation, it can replace most situations where liquid level switches are used.

With the continuous development of technology, pressure controllers, as an emerging technological force, have occupied the pressure control market and become a strategic requirement for the development of China's industry. They are not only suitable for industrial petroleum and coal mines, but also begin to appear in modern household appliances. It can be seen that pressure controllers are becoming increasingly important.

Pressure controller is mainly a type of pressure control product, which plays a role in timely controlling pressure and controlling the start and stop status of equipment in industry, agriculture, and modern life. Take the familiar boiler as an example. A boiler is a relatively dangerous energy equipment. Once its pressure is not controlled, the accident rate is very high. The pressure controller plays an irreplaceable role inside. When the boiler pressure reaches the rated value, the pressure controller will control the boiler to stop working in a timely manner. When the pressure returns to the safe pressure value, the boiler will restart working.
