BENTLY135137-01 is a 4-channel position input/output module in the Bently Nevada 3500 series mechanical protection system, fully integrated into the 3500/45 monitoring system. This module is the "position monitoring core" of the 3500 monitoring system, responsible for receiving signals from various position sensors and converting them into digital signals for processing and analysis. In the protection system of large rotating machinery such as steam turbines, compressors, and generators, this position I/O module is an important component that ensures real-time monitoring and protection of key parameters such as axial displacement, differential expansion, and shell expansion.

BENTLY 135137-01 provides 4 independent channels, each of which can be flexibly configured and supports multiple sensor input types:

Eddy current sensor (Proximitor): used for monitoring radial vibration and axial displacement

Rotary Position Sensor (RPT): used for monitoring valve position and actuator position

DC/AC Linear Variable Differential Transformer (DC/AC LVDT): Used for high-precision displacement measurement

Rotary Potentiometer: used for angle and position monitoring

Channels can be programmed in pairs and can perform up to two different monitoring functions simultaneously, greatly enhancing the flexibility and application scope of the module.

The core value of this module lies in its real-time alarm protection capability. By continuously comparing the monitoring parameters with the user's preset alarm values (Alert) and hazard values (Danger), once the monitoring value exceeds the limit, the module will immediately trigger an alarm, drive the relay output, and achieve protection shutdown or sound and light alarm.

The module is equipped with high-precision signal processing algorithms that perform digital signal processing such as filtering, amplification, and calibration to ensure measurement accuracy and reliability. The alarm set points and monitoring parameters can be programmed and configured through the 3500 configuration software to meet the personalized protection needs of different devices.

BENTLY 135137-01 supports monitoring of the following key mechanical parameters:

Thrust Position: Monitor the axial movement of the rotor relative to the cylinder to prevent friction between moving and stationary components

Differential Expansion: Monitor the length difference between the rotor and cylinder due to different coefficients of thermal expansion, to prevent collisions during unit start-up or variable operating conditions

Case Expansion: Monitor the thermal expansion of the casing and evaluate the operating status of the unit

Eccentricity: Monitoring the bending state of the rotor, mainly used for protection during the start stop phase of the unit

Radial Vibration: Monitor the vibration amplitude of the rotor inside the bearing and evaluate the balance state of the bearing and rotor

BENTLY 135137-01 position I/O module is widely used in industrial fields that require the highest level of mechanical protection:

Power industry: monitoring of axial displacement, differential expansion, and shell expansion of steam turbines, gas turbines, and generators

Oil and gas: position monitoring and interlocking protection of compressor units and pump groups

Chemical industry: monitoring the position and status of key equipment such as reactors and mixers

Metallurgical industry: position monitoring of heavy equipment such as rolling mill main motors and fans

Aerospace: Position Control and Monitoring of Engines and Moving Parts

Product model 135137-01

Manufacturer Bently Nevada (Baker Hughes)

Belonging to series 3500/45

Product Type Position Input/Output Module with Internal Terminals

Number of channels: 4 independent channels

Support sensors, eddy current sensors RPT、DC/AC LVDT、 Rotary potentiometer

Monitoring functions include axial displacement, differential expansion, shell expansion, eccentricity, and radial vibration

Input voltage 24 VDC or 125 VDC

Output voltage 24 VDC

Communication interface RS-485

Memory capacity 256 KB

Working temperature -40 ° C to+65 ° C

Storage temperature -40 ° C to+85 ° C

Protection level IP67

Dimensions (height x width x depth) 241 mm x 24.4 mm x 99.1 mm

Weight approximately 0.44 kg

Installation position: 3500 rack full height slot
