In distribution feeder substations, the GE UR6AV connects to recloser controls and SCADA while driving trip/close coils directly through its 8 A rated outputs, eliminating external auxiliary relays. Deploying multiple GE UR6AV modules across UR-series relays enables distributed scheme logic for auto-reclose sequences, load shedding, and interlock protection without compromising scan times. The GE UR6AV hot-swappable design supports field expansion during live operation, ideal for upgrading legacy electromechanical schemes to IEC 61850 digital substations.

Model UR6AV

Product Type Digital I/O Module (UR series)

Digital Inputs 8 dry contacts, 24–250 VDC/24–230 VAC, 2 mA wetting current

Form-A Outputs 2 (NO), 8 A make/6 A carry, 250 VAC/30 VDC

Form-C Output 1 (CO), 8 A make/6 A carry

Latching Outputs 2 (shared with Form-A)

Isolation 2 kV RMS input-output-earth

Operate Time<4 ms (Form-A), programmable

Power Supply 24 VDC from UR backplane

Operating Temp −40°C to +70°C

Dimensions/Weight Standard UR module size, ~0.4 kg

Slot preparation

Power down UR relay chassis and identify available I/O expansion slot for GE UR6AV.

Module insertion

Slide GE UR6AV into slot until backplane connectors engage; secure with captive screws.

Field wiring

Connect status inputs and trip coil outputs to GE UR6AV terminals per scheme diagram.

Configuration

Program GE UR6AV logic in EnerVista UR Setup via FlexLogic; assign virtual outputs.

Commissioning

Test input debounce and output timing through GE UR6AV diagnostic LEDs.

Verify input voltage polarity before energizing GE UR6AV to prevent false indications.

Use shielded cables for GE UR6AV inputs routed near high-voltage CT circuits.

Torque terminal screws to 1 Nm on GE UR6AV for vibration resistance.

Confirm UR relay firmware supports GE UR6AV (v5.9x or later recommended).

Separate GE UR6AV trip outputs from non-critical control wiring.

Monthly: Monitor GE UR6AV LEDs for stuck contacts or input failures.

Quarterly: Test GE UR6AV output continuity with dry circuit tester.

Annually: Verify GE UR6AV timing through secondary injection during protection tests.

Clean GE UR6AV edge connectors during chassis maintenance.

Log GE UR6AV FlexLogic execution faults for scheme optimization.
