In transformer substations, the GE SR745-W2-P1-G1-HI-A-L-R is used to protect two- or three-winding transformers from internal faults, overloads, and abnormal operating conditions. The GE SR745-W2-P1-G1-HI-A-L-R supports adaptive harmonic restraint, multiple setting groups, and FlexLogic-style programmable outputs, which helps reduce nuisance trips while keeping protection fast and selective. With its enhanced display and multiple communication interfaces, the GE SR745-W2-P1-G1-HI-A-L-R is suitable for both new installations and retrofit projects.

Model GE SR745-W2-P1-G1-HI-A-L-R

Product type Transformer management relay

Protection functions Differential, overcurrent, overvoltage, undervoltage, overexcitation, frequency, harmonic restraint

Control power 90–300 VDC or 70–265 VAC, 40 VA, 48–62 Hz

Communication Ethernet, RS-232, RS-485, RS-422; Modbus and DNP 3.0 level 2

Operating temperature −40 °F to +140 °F

Humidity Up to 90% non-condensing

Altitude Up to 2000 m

Display Enhanced 40-character display with extended keypad

Enclosure / chassis 745 SR series chassis, IP40 / IP20

Mount the GE SR745-W2-P1-G1-HI-A-L-R in a standard transformer relay panel or 19-inch rack, leaving enough space for the door to open freely.

Connect the control power supply within the specified voltage range to the GE SR745-W2-P1-G1-HI-A-L-R.

Wire CTs, VTs, and transformer auxiliary contacts to the GE SR745-W2-P1-G1-HI-A-L-R according to the protection scheme.

Configure communication ports on the GE SR745-W2-P1-G1-HI-A-L-R for Ethernet or serial integration with SCADA or engineering software.

Download protection settings, verify trip logic, and test alarm and trip outputs before energizing the transformer.

Verify CT polarity and transformer ratio settings before commissioning the GE SR745-W2-P1-G1-HI-A-L-R.

Ensure correct grounding and shielding for all measurement cables connected to the GE SR745-W2-P1-G1-HI-A-L-R.

Keep the relay within the specified temperature and humidity limits to avoid instability.

Do not block the panel ventilation space around the GE SR745-W2-P1-G1-HI-A-L-R.

Use only approved settings files and test procedures for the GE SR745-W2-P1-G1-HI-A-L-R.

Periodically check event logs and relay diagnostics on the GE SR745-W2-P1-G1-HI-A-L-R.

Inspect terminal screws and wiring condition during shutdowns.

Back up protection settings and logic groups for the GE SR745-W2-P1-G1-HI-A-L-R before firmware or maintenance work.

Test communication links and trip circuits regularly to confirm the GE SR745-W2-P1-G1-HI-A-L-R is functioning properly.

Review harmonic restraint and setting-group behavior during routine protection audits.
