The GE SLN080 IC086SLN080-A (also referenced as IC086SLN080) is a compact, industrial-grade 8-port unmanaged Ethernet switch from the GE / Emerson PACSystems series. Designed for harsh industrial environments, the GE SLN080 IC086SLN080-A provides reliable, plug-and-play network connectivity with eight 10/100BaseT(X) RJ45 ports, supporting full-duplex operation and auto-negotiation for seamless integration in factory automation, process control, and turbine auxiliary networks.

The GE SLN080 IC086SLN080-A features extended temperature range, redundant power inputs, and a rugged enclosure, making the GE SLN080 IC086SLN080-A ideal for connecting HMIs, controllers, I/O packs, and other Ethernet devices in GE Speedtronic Mark VIe systems or general industrial applications. Its mini form factor reduces panel space while delivering high reliability and minimal maintenance. Whether used in new installations or network expansions, the GE SLN080 IC086SLN080-A ensures stable, interference-resistant data transmission in demanding power generation and automation environments.

Model,GE SLN080 IC086SLN080-A (IC086SLN080)

Module Type,Industrial 8-port Mini Unmanaged Ethernet Switch

Ports,8 × 10/100BaseT(X) RJ45 (auto MDI/MDI-X)

Ethernet Standards,"IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3x (Flow Control)"

Switching Method,Store-and-Forward

MAC Address Table,2048 entries

Power Supply,Redundant 12–48 V DC (typical 24 V DC)

Power Consumption,Approx. 4 W (typical)

Operating Temperature,-40°C to +70°C

Storage Temperature,-40°C to +85°C

Humidity,"5% to 95% RH, non-condensing"

Dimensions (W × D × H),Approx. 26.1 mm × 94.9 mm × 144.3 mm

Weight,Approx. 0.39–0.42 kg

Mounting,DIN-rail or panel mount

Enclosure Rating,IP30

Protections,"Overload current, reverse polarity, ESD, surge"

Compatibility,"GE PACSystems, Mark VIe auxiliary networks, industrial Ethernet"

Operating the GE SLN080 IC086SLN080-A is straightforward due to its unmanaged “plug-and-play” design:

Connect the redundant power supply (12–48 V DC) to the dual power input terminals of the GE SLN080 IC086SLN080-A.

Attach Ethernet cables (CAT5e or better, up to 100 m) to the eight RJ45 ports as needed for devices such as controllers, HMIs, or I/O packs.

Power on the switch; all ports automatically negotiate speed and duplex mode.

Verify link/activity LEDs on each port of the GE SLN080 IC086SLN080-A to confirm active connections.

Monitor network traffic and device communication through connected equipment (no local configuration required).

In case of link failure, check cable integrity and port LEDs on the GE SLN080 IC086SLN080-A.

Periodically review system diagnostics in the host controller to ensure stable data flow through the GE SLN080 IC086SLN080-A.

Proper installation ensures long-term reliability of the GE SLN080 IC086SLN080-A. Always de-energize the power supply before wiring. Use ESD-safe practices when handling the module. Mount the GE SLN080 IC086SLN080-A securely on a DIN rail or panel in a well-ventilated location with adequate clearance for heat dissipation. Connect redundant power sources (separate feeds recommended) using appropriate wire gauge and torque. Use shielded Ethernet cables where possible in noisy environments and maintain proper grounding. Avoid routing cables near high-voltage lines. After installation, power up the GE SLN080 IC086SLN080-A, check all port LEDs, and perform basic ping/communication tests with connected devices before integrating into the control network. Only qualified technicians should install the GE SLN080 IC086SLN080-A.

Routine maintenance helps sustain optimal performance of the GE SLN080 IC086SLN080-A:

Visually inspect the GE SLN080 IC086SLN080-A for dust buildup, loose cables, or damaged ports during scheduled outages.

Clean the exterior and ventilation areas gently with dry compressed air — never use liquids or solvents.

Check power supply voltages and confirm both redundant inputs are healthy.

Verify link and activity LEDs on all eight ports of the GE SLN080 IC086SLN080-A are functioning correctly.

Monitor network performance (latency, packet loss) through connected controllers or diagnostic tools.

Ensure operating temperature remains within -40°C to +70°C and the environment stays dry and vibration-free.

Record any anomalies (e.g., persistent link failures) and schedule inspection or replacement every 2–3 years (or per plant policy) to maintain the reliability of the GE SLN080 IC086SLN080-A.

Following these guidelines ensures the GE SLN080 IC086SLN080-A provides continuous, high-availability Ethernet connectivity in critical industrial and turbine control applications. For official datasheets, user manuals, or firmware-related support (though unmanaged), consult authorized GE / Emerson documentation or your local representative.
