The ABB  REC670 is a high performance bay control and protection IED designed for medium  and high voltage substations. It integrates measurement, control, and protection functions in a single compact device, making the ABB REC670 ideal for modern, distributed substation automation systems. The ABB REC670 offers a flexible functional library, extensive configuration options, and scalable hardware to meet a wide range of grid applications.

Model ABB REC670 bay control IED

Typical application Bay control, protection, and monitoring for transmission and distribution substations

Functions Measurement, control, protection, autoreclosing, synchronism check, disturbance recording

Voltage level Suitable for high voltage and extra high voltage bays (applicationdependent)

I/O capability Large number of binary inputs/outputs and analog channels, scalable by hardware modules

Communication IEC 61850, IEC 60870 5 103, SPA, LON, and other substation communication protocols (option dependent)

Time sync Support for time synchronization via IEC 61850 and external time sources (e.g., GPS, station clock)

HMI Large local HMI for single line diagram display, local control and event viewing

Disturbance recording Integrated disturbance and event recorder for fault analysis

Configuration tool PC based software for setting, logic configuration, and disturbance evaluation

Ensure the ABB REC670 is correctly wired, grounded, and mounted in the bay panel, and confirm that all primary equipment is in a safe condition.

Power up the ABB REC670 and verify that the device passes its self supervision checks and shows healthy status on the HMI/status LEDs.

Use the ABB configuration software to load the bay configuration, protection settings, and control logic into the ABB REC670 according to the project design.

From the local HMI of the ABB REC670, check the single line diagram, measured values, and device status to confirm that signals are correct.

Perform interlocking, switching, and protection function tests on the ABB REC670 as per the commissioning procedure, including trip and close commands.

After successful tests, place the ABB REC670 into service mode and record all relevant settings and firmware versions for future maintenance.

Install the ABB REC670 in a clean, dry, and temperature controlled switchgear or protection panel, following the specified mounting guidelines.

Provide adequate space for ventilation around the ABB REC670 and avoid routing high voltage or high current cables directly above or behind the device.

Use proper shielding and grounding practices when connecting CT/VT circuits and communication interfaces to the ABB REC670.

Clearly label all terminals and auxiliary circuits associated with the ABB REC670 to simplify operation and maintenance.

Before energizing, double check polarity, CT/VT ratios, and wiring correctness to prevent mis operation of the ABB REC670.

Regularly inspect the ABB REC670 front panel, terminals, and surrounding wiring for contamination, looseness, or mechanical damage.

Periodically review disturbance records, event logs, and alarm history in the ABB REC670 to detect abnormal operating patterns.

Verify the accuracy of key measurements and protection functions of the ABB REC670 during scheduled maintenance, using secondary injection tests where required.

Keep the configuration files, setting reports, and firmware release notes of each ABB REC670 safely archived for quick restoration or replacement.

When system conditions change (such as network reconfiguration or protection setting updates), re evaluate and, if necessary, adjust the settings of the ABB REC670 under a controlled procedure.
