16 channel independent configuration: supports 4-20mA current or 1-5VDC voltage input, HART v5.4 communication.

High speed sampling: Update all 16 channels in 100ms, with adjustable A/D resolution of 12-16 bits and polarity.

Intelligent diagnosis: 96mA short circuit current limiting protection,<5-second open circuit detection, automatic fault alarm.

Group isolation design: 2 groups of 8-channel independent isolation, strong anti-interference, DIN rail horizontal installation.

Flexible compatibility: Single/redundant, compact/full-size base universal, mechanical anti misoperation key locking.

Installed on the xBS01 FPH or xBS01 EPD base, fixed with a 35mm DIN rail to ensure grounding.

Connect 4-20mA field instruments and communicate with HART devices through channel 1/9 modems.

FC221 configures module parameters, FC222 sets engineering units and alarm limits for each channel.

Verify signal range and update rate, monitor diagnostic LED. Safety reminder: On site hot plugging support, backup configuration before power failure.

Model AI02

Manufacturer ABB

Type Analog Input Module (HART)

Number of channels 16 (2 × 8 groups isolated)

Input range 4-20mA/1-5VDC

A/D resolution 12-16 bits (with polarity)

Update time 100ms (all 16 channels)

Accuracy ± 0.1% FSR

Short circuit protection with 96mA current limit

Open circuit detection<5 seconds

Power supply voltage 24V DC (provided by the base)

Working temperature -25 ° C to+70 ° C

Installation method: 35mm DIN rail

Communication protocol HART v5.4 (channel 1/9)

Base compatible with xBS01-FPH/EPD

This rack-mounted ABB SD Series I/O setup shows the AI02 module alongside similar units, highlighting its compact horizontal row design for control cabinets.

The ABB AI02 analog input module is designed specifically for Symphony Plus distributed control systems, processing 16 high-level analog field signals and supporting HART intelligent instrument communication. A single A/D converter ensures synchronous sampling and built-in protection mechanism enhances system reliability. The modular design is compatible with all SD series bases and is widely used in chemical, power, and oil and gas process control. Keywords: ABB AI02 analog input, Symphony Plus HART module, SD series I/O, 16-channel AI module, 4-20mA HART input, industrial DCS analog acquisition.

AI01: No HART version, dual A/D converter 22.5m/s channel update.

AI03/AI04: Extended voltage range, -10/+10VDC support.

DO02: Comes with a 16 channel digital output module.

Q: How to implement HART communication?

A: Built in 1 HART modem service for two groups (channel 1/9), supporting v5.4 protocol multi device polling.

Q: How fast is the update rate?

A: Update all 16 channels in 100ms, which is 80% faster than AI01's 180ms.

Q: What bases are supported?

A: The xBS01 series is fully compatible (single/redundant, compact/full-size), with mechanical keys to prevent accidental insertion.

Q: On site protection function?

A: 96mA current limit anti short circuit,<5-second open circuit detection, real-time upload of diagnostic data to the controller.
