Honeywell MasterLogic-200 2MLI-CPUU Central Processing Module、

The 2MLI-CPUU acts as the central command node for non-redundant MasterLogic installations. Operating on a clean refresh system (scan-synchronous batch processing), the CPU ensures all digital inputs, analog levels, and counter metrics are stabilized during the scan interval before executing application logic or committing output statuses.

The onboard system housing features embedded serial communication options (RS-232C / RS-485) and an Ethernet interface to handle peer-to-peer data transfers between neighboring MasterLogic assemblies over UTP or fiber networks.For storage protection, the CPU is backed by a 16MB integrated flash partition that preserves machine logic maps, variable presets, and diagnostic tracking files during primary power interruptions.

Engineering Specification Dataset：

System Metric	Certified Value / Operating Parameter
Manufacturer	Honeywell Process Solutions
Model Nomenclature	2MLI-CPUU
System Classification	Non-Redundant Standard CPU Controller
Base Hardware Architecture	High-performance 32-bit Embedded Microprocessor
Basic Instruction Speed (LD)	0.028 microseconds per step
Total Program Memory Space	7 Megabytes (MB)
Dedicated System Memory	4 Megabytes (MB)
Retentive Variable Space (M)	256 Kilobytes (KB) Max 128 KB Retain Settable
Maximum Local Chassis Support	1 Main Base + 7 Extension Bases (8 Total Racks)
Max Expandable I/O Slots	96 Slots maximum across system topology
Addressable I/O Point Capacity	Up to 6,144 points (utilizing 64-channel modules)
Logic Framework Compliance	IEC 61131-3 International Standards
Embedded Networking Capabilities	Fast Ethernet, RS-232C, RS-485 Serial Lines
Working Environment Limits	0°C to +55°C (32°F to 131°F) at 5% to 95% RH
Module Mass & Size	Approx. 0.35 kg to 0.50 kg \| Compact rail-mount form-factor

2MLI-CPUU

Key Application Contexts：

Water & Wastewater Facilities: Controls chemical dosing loops, multi-pump alternation algorithms, and filter backwashing sequences in public water infrastructure.
Packaged Power & Boiler Skids: Runs safety-interlock sequences, draft fan controls, and fuel-to-air ratio calculations for auxiliary burner installations.
Food & Beverage Production: Regulates clean-in-place (CIP) operations, batch pasteurization systems, and multi-ingredient weighing hoppers.
Automobile Manufacturing Skids: Manages fast-moving conveyor transfers, assembly line lifters, and pneumatic terminal blocks on factory floors.

Primary Capabilities & Practical Advantages：

Ultra-Fast Logic Processing: Runs basic instructions (LD) at 0.028 µs per step and data movement tasks (MOV) at 0.084 µs per step to maintain instantaneous process loops.
Seamless Control Room Integration: Provides out-of-the-box handshake protocols with Honeywell Experion architectures for direct clock synchronization, native hardware diagnostics, and unified PLC system alerting.
Flexible Execution Profiles: Offers cyclic scans, time-driven interrupt intervals, and internal memory threshold triggers to adapt smoothly to highly complex automation sequences.
Large Scale I/O Management: Allows cost-effective network expansion, managing up to 8 discrete chassis arrangements (1 main base plus up to 7 remote extensions) for a maximum footprint of 96 active module slots.
Comprehensive Programming Freedom: Fully supports international standard IEC 61131-3 languages including structured text (ST), sequential function charts (SFC), and traditional ladder diagrams (LD).
