HONEYWELL 2MLF-AV8A Analog Input Module

The Honeywell 2MLF-AV8A module is engineered for reliable analog signal acquisition in demanding industrial environments. It provides 8 independent voltage input channels and supports multiple configurable input ranges, enabling flexible integration with sensors and field instruments.

Its internal A/D conversion system ensures fast processing and accurate signal translation, making it suitable for real-time control systems such as SCADA, DCS, and PLC-based automation networks.

Designed for modular PLC systems, the module delivers stable performance under electrical noise, temperature variation, and continuous industrial operation.

Model: 2MLF-AV8A
Manufacturer: Honeywell
System Compatibility: MasterLogic-200 PLC Series

Input Characteristics

• Input Type: Voltage analog input

• Number of Channels: 8 channels per module

• Input Ranges:

• 1–5 V DC

• 0–5 V DC

• 0–10 V DC

• –10 to +10 V DC

• Input Resistance: ≥ 1 MΩ

Conversion Performance

• Conversion Type: A/D conversion (Analog to Digital)

• Resolution: 16-bit digital output format

• Conversion Speed: approx. 250 µs per channel

• Output Formats:

• Unsigned value (0–16000)

• Signed value (–8000 to +8000)

• Scaled precise value

• Percentile scaling

Electrical Data

• Power Consumption: approx. 420 mA @ 5 V DC

• Isolation Method: Photo-coupler isolation between input and system power

• Channel Isolation: Not isolated between channels

Physical & Installation

• Terminal Type: 18-point terminal block

• Module Type: Plug-in PLC I/O module

• Weight: approx. 0.14 kg

Environmental Conditions

• Operating Temperature: industrial-grade range (typical PLC environment)

• Designed for electrical noise immunity and continuous operation

1. High-Density 8-Channel Input

Supports multiple sensors in a single module, reducing system footprint and wiring complexity.

2. Multi-Range Voltage Compatibility

Accepts standard industrial voltage signals including 0–10 V and ±10 V ranges.

3. Fast Signal Conversion

High-speed A/D conversion ensures real-time process response with minimal delay.

4. Stable Industrial Operation

Designed to withstand electromagnetic interference and harsh factory environments.

5. Flexible Data Output Formats

Supports multiple scaling formats for seamless PLC program integration.

6. Modular System Integration

Fully compatible with Honeywell MasterLogic-200 distributed control systems.

The HONEYWELL 2MLF-AV8A is used across multiple industrial automation sectors:

• Oil & gas processing plants

• Petrochemical production systems

• Power generation and distribution

• Water treatment and utilities

• Industrial manufacturing automation

• SCADA monitoring systems

• Process control instrumentation

• Temperature, pressure, and flow monitoring systems

• Chemical processing plants

• Heavy industrial machinery control systems

• Analog voltage signal acquisition

• Real-time A/D conversion processing

• Signal scaling and normalization

• Fault detection and module diagnostics

• PLC system data communication

• Multi-channel sensor integration

Q1: What is the main function of the 2MLF-AV8A?

It converts analog voltage signals into digital data for PLC-based control systems.

Q2: How many input channels does it support?

It provides 8 independent analog voltage input channels.

Q3: What voltage ranges are supported?

It supports 1–5 V, 0–5 V, 0–10 V, and ±10 V DC input ranges.

Q4: Is it suitable for industrial environments?

Yes, it is designed for harsh industrial environments with noise immunity and stable performance.

Q5: What system is it compatible with?

It is designed for Honeywell MasterLogic-200 PLC systems.
