Honeywell CC-TDOB01 Experion Series C 32-Channel Bussed Digital Output IOTA

The CC-TDOB01 provides robust, compact field termination for high-density discrete outputs within Honeywell's Experion Process Knowledge System (PKS).Mating seamlessly with the CC-PDOB01 output module, it distributes 24 VDC power across 32 individual channels via a shared internal bus structure. To maximize plant runtime, each channel features an independent overcurrent monitoring loop. When an external short-circuit or fault occurs, the board isolates only the compromised point, triggers a dedicated alarm, and leaves the remaining 31 channels completely unaffected and operational.

Model Technical Specifications & Details：

Technical Parameters:

Part Number: 51308371-175 / 51306515-100
Total Available Channels: 32 Output Points
Output Interface Configuration: Bussed 24 VDC (Common Return Architecture)
Nominal Operating Voltage: 24 V DC
Maximum Continuous Load Current: 0.5 A per channel
Overcurrent Protective Threshold: Automatic shutdown activated above 0.5 A
Galvanic Base Isolation: 1500 V AC between field terminal array and internal processing logic
Maximum Total Board Capacity: 16 A aggregate throughput
Physical Footprint Profile: Standard Series C 6-inch IOTA carrier mounting

Key Features & Advantages:

Per-point short-circuit tracking instantly transitions a tripped channel into Manual mode to prevent broad hardware down-time.
Generates localized "Over-current Soft Failure" alerts directly within the Experion PKS diagnostic environment.
Heavy-gauge screw terminals allow reliable termination of multi-core field cables up to 12 AWG.

Applications:

Driving high-density matrix display indicator panels in centralized marshalling hubs.
Command signaling for interlocked low-voltage motor control center (MCC) starter coils.
Sequencing large arrays of 24V solenoid-actuated pneumatic process valves.

CC-TDOB01

Application Areas：

Petrochemical Plants & Refineries: Execution of safety-interlock logic, block valve routing, and automated isolation valve arrays.
Automated Material Handling: Command distribution for continuous conveyor tracks, sortation gates, and safety warning sirens.
Water & Wastewater Treatment: Managing discrete status inputs and sequencing backwash pumps, aerators, and chemical storage isolation gates.
Pharmaceutical Batch Processing: Actuating multi-port product distribution manifolds and clean-in-place (CIP) system flush valves.

FAQ：

Q: How does the CC-TDOB01 react when a direct short-circuit occurs on a single field solenoid?

A: The internal circuitry detects the overcurrent condition instantly and shuts down only that specific output.The affected point drops into Manual mode and throws an "Over-current Soft Failure" alarm in Experion. All other 31 channels continue operating without interruption.

Q: Can this IOTA be configured to handle dry contact relay operations directly?

A: No. The CC-TDOB01 provides active 24 VDC bussed power directly down the line to drive loads. If your application calls for dry contacts (SPDT/Form C), you must deploy the Honeywell CC-TDOR01 or CC-TDOR11 relay output IOTA variants instead.

Q: Is there an onboard thermal alarm integrated into the hardware assembly?

A: Yes. If an external field fault draws excessive current, a secondary thermal alarm triggers when the localized short circuit profile exceeds 0.5A, providing an extra tier of physical board protection.
