This module is designed for 3500 series mechanical protection systems, supports EGD (Ethernet Global Data) communication, and can be integrated with EGD compatible controllers for real-time data exchange.

The 3500/91 also supports 10BASE-T and 100BASE-TX Ethernet standards, making it suitable for transmitting data monitored by the 3500 rack to PLC, DCS, or other control platforms.

Manufacturer Bently Nevada

Model 3500/91

Type EGD Communication Gateway Module

Protocol EGD 2.01, Ethernet UDP/IP

Ethernet standard IEEE 802.3, 10BASE-T/100BASE-TX

Power consumption 7.4 W typical

Working temperature -30 ° C to+65 ° C

Main module size 241.3 mm x 24.4 mm x 241.8 mm

Main module weight 0.79 kg

I/O module size 241.3 mm x 24.4 mm x 99.1 mm

I/O module weight 0.39 kg

Rack requirement: 1 full height front slot+1 full height rear slot

Application 3500 rack data communication, controller integration

Q1: What is the main function of 3500/91?

It is responsible for sending monitoring data and status from the 3500 rack to the external control system via Ethernet.

Q2: What protocols does 3500/91 support?

Public information shows support for EGD and Ethernet UDP/IP.

Q3: Do I need to use it in conjunction with other modules?

Yes, the information indicates that 3500/92M TDI is required for 3500/91 EGD to communicate with the monitoring module.
