This module converts the alarm status (Alert, Danger) or system status (Not OK) of the 3500 monitoring module into reliable hard wired relay contact outputs, supporting direct control of external alarm indications, shutdown circuits, or control logic.

Each relay channel contains programmable alarm driver logic that supports AND/OR logic operations. It can trigger alarm actions based on multiple measurement variables or channel combinations, achieving flexible alarm strategy configuration.

Mainly used in mechanical protection systems for rotating equipment such as steam turbines, compressors, pumps, generators, etc., to ensure reliable triggering of external response mechanisms in the event of a fault.

Manufacturer Bently Nevada

Product Code 149986-01

Model 3500/33

Type 16 Channel Relay Module (Full Height Module)

Bently Nevada 3500 Monitoring System

16 independent relay channels

Programmable AND/OR logic for relays

Power consumption~8 Watts

Size 241.3 x 24.4 x 241.8 mm (approximately 16x16x12cm)

Weight 0.76kg

Apply Alarm Indication, Shutdown Control

Q1: What are the main functions of 3500/33 149986-01?

Provide 16 independent relay outputs to convert the alarm status of the 3500 system into a hard wired signal to drive external devices.

Q2: What alarm logic does this module support?

Supports programmable AND/OR logic and can trigger relay actions based on multiple channel combinations.

Q3: What are the module dimensions and weight?

The size is approximately 16cm x 16cm x 12cm, with a weight of 0.76kg, and it belongs to the full height module.

Q4: For what devices?

Mechanical protection system suitable for rotating equipment such as steam turbines, compressors, pumps, etc.
