The GE VMIVME-3122 (also known as VMIVME3122 or VME-3122) is a high-performance 16-bit Analog-to-Digital Converter (ADC) board designed for VMEbus systems. Manufactured by GE Fanuc / VMIC / Abaco Systems, the GE VMIVME-3122 provides 64 differential or single-ended analog input channels with continuous scanning capability, making it ideal for real-time data acquisition in industrial automation, process control, turbine monitoring, and laboratory applications.

The GE VMIVME-3122 features program-selectable gain (x1 or x10), software-selectable conversion rates up to 100 kHz (high-performance version), multiple trigger and scan modes, and a large dual-port data buffer. Its robust design, high accuracy, and flexible configuration make the GE VMIVME-3122 a reliable choice for high-resolution analog signal digitization in demanding VME-based control environments.

Model,GEVMIVME-3122

Module Type,16-bit Analog-to-Digital Converter (ADC) Board

Input Channels,64 differential or single-ended (scalable to 32 or 16)

Resolution,16-bit

Conversion Rate,"Up to 100 kHz (high-performance), 50 kHz (standard)"

Input Ranges,"±2.5V, ±5V, ±10V, 0 to +5V, 0 to +10V (jumper selectable)"

Programmable Gain,x1 or x10 per channel

Data Buffer,"1,024-word dual-port (16-word deep × 64 channels)"

Scan Modes,"Autoscan, Single Scan, Random Access"

Trigger Modes,"Software, External, Interval Timer"

Input Filters,"Optional low-pass (10 Hz, 50 Hz, 100 Hz, 500 Hz)"

Accuracy,±0.005% of reading + ±0.005% of range + 100 µV

Isolation / Protection,Overvoltage protected inputs

VMEbus Interface,"A32/A24/A16 : D16/D8, interrupter"

Power Requirements,+5V @ 1.2 A max (VMEbus slot only)

Operating Temperature,0°C to +55°C (typical industrial)

Form Factor,6U VMEbus double height

Compatibility,"VMEbus systems, GE Mark VI / Mark VIe auxiliaries"

Operating the GE VMIVME-3122 within a VMEbus system follows standard procedures:

Install the GE VMIVME-3122 in the VME chassis and connect analog input signals via the front-panel connectors (64-pin or 96-pin).

Power up the system and verify board recognition through VMEbus access or diagnostic software.

Configure input ranges, gain, scan mode, conversion rate, and trigger mode via software or CSR registers.

Initiate scanning (autoscan is default after reset) and read digitized data from the dual-port buffer at any time.

Monitor real-time analog values, buffer status, and interrupts through the host controller or application software.

During normal operation, the GE VMIVME-3122 continuously digitizes selected channels and stores results for fast access.

Use programmed interrupts or data-ready flags to synchronize data processing with the GE VMIVME-3122.

Proper installation is critical for accurate performance of the GE VMIVME-3122. Always de-energize the VME chassis and follow lockout/tagout procedures before insertion. Use ESD-safe practices when handling the board. Set jumpers for input range, polarity, and filter options before installation. Connect analog signals to the appropriate 64-pin or 96-pin connectors with correct shielding and grounding to minimize noise. Ensure proper VMEbus address and interrupt configuration. After installing the GE VMIVME-3122, perform calibration, loop checks on all channels, and full system diagnostics before commissioning. Only qualified technicians experienced with VMEbus analog I/O boards should install or service the GE VMIVME-3122.

Routine maintenance ensures long-term accuracy and reliability of the GE VMIVME-3122:

Visually inspect the GE VMIVME-3122 for dust, loose connectors, or signs of overheating during scheduled outages.

Clean the board and connectors gently with dry compressed air — never use liquids or solvents.

Review VMEbus diagnostic logs and data buffer integrity daily for any conversion errors or interrupt issues.

Verify input signal levels and compare digitized values against known references.

Check operating temperature remains within 0°C to +55°C and the environment stays dry.

Confirm scan rates, gain settings, and trigger modes remain as configured.

Record any anomalies and schedule professional calibration or inspection annually (or per plant policy) to maintain the high precision of the GE VMIVME-3122.
