The GE VMIACC-5595-208 is a managed reflective memory hub designed for use with GE Fanuc reflective memory real-time network products. It provides up to eight fiber-optic ports using SFP transceivers, enabling high-speed, low-latency data transfer in industrial control and automation systems. The GE VMIACC-5595-208 can automatically bypass ports on loss of signal or synchronization so that the remaining network nodes continue operating. It supports both multimode and single-mode fiber for short- and long-distance networking and can be used in cascaded configurations to build large networks. The GE VMIACC-5595-208 is typically supplied as a 19-inch 1U rack-mount or desktop module with a universal AC power input.

Model GE VMIACC-5595-208 reflective memory hub

Function type Managed reflective memory hub assembly

Compatible products GE VMIxxx-5565 / 5565-series reflective memory modules

Number of ports Up to 8 SFP fiber-optic ports

Data rate 2 Gb/s reflective memory network speed

Fiber types Multimode (short-range) and single-mode (long-range) SFP transceivers

Multimode wavelength Approximately 830–860 nm

Multimode max distance Up to about 300 m (typical)

Single-mode (10 km) λ Approximately 1300–1335 nm (typical)

Single-mode (10 km) dist Up to about 10 km (typical)

Single-mode (80 km) λ Approximately 1540–1570 nm (typical)

Single-mode (80 km) dist Up to about 80 km (typical)

Management interfaces RS-232 serial port, Ethernet (remote monitoring via web browser)

Mounting options 19-inch 1U rack-mount or desktop enclosure

Typical dimensions Approx. 1U high, 19-inch wide; depth around 250–300 mm (varies by version)

Power requirements Universal AC 90–264 V, 47–440 Hz, about 25 W

Safety / EMC Designed to meet UL / CE and related EMC standards (e.g. EN55022, EN61000-4 series)

Install the GE VMIACC-5595-208 in the rack or on a stable desktop and connect the AC power cord.

Insert the appropriate SFP transceivers (multimode or single-mode) into each port of the GE VMIACC-5595-208 as required by the network design.

Connect fiber-optic cables from the GE VMIACC-5595-208 ports to the corresponding reflective memory nodes.

Power on the hub and connected nodes, then verify port status LEDs for link, signal, and synchronization.

Use the RS-232 or Ethernet interface (web browser) to view status, configure port modes, and set any bypass or “dark-to-dark” options as needed.

Ensure power is disconnected before wiring or inserting/removing SFP transceivers in the GE VMIACC-5595-208.

Use only compatible SFP modules and fiber types; avoid excessive bending or stress on fiber-optic cables.

Mount the GE VMIACC-5595-208 in a well-ventilated area, leaving space around the air inlets and outlets.

Follow ESD protection procedures when handling the GE VMIACC-5595-208 or SFP modules.

Label all ports and fibers clearly to simplify troubleshooting and future maintenance.

Periodically inspect the GE VMIACC-5595-208 front panel to check LED indications for abnormal ports or alarms.

Keep vents and the enclosure of the GE VMIACC-5595-208 free from dust; clean gently with dry air or a soft brush.

Check fiber connectors for contamination and clean them using proper fiber-optic cleaning tools if link quality degrades.

Back up configuration data and document network topology including all GE VMIACC-5595-208 settings.

If used in harsh environments, schedule regular checks of power connections and verify that the GE VMIACC-5595-208 operates within specified temperature and humidity limits.
