The GEV7768-322001 is a high-performance dual-slot VMEbus single board computer (SBC) originally developed by GE Fanuc Intelligent Platforms (now part of Abaco Systems). Powered by an Intel Core 2 Duo processor running at up to 2.16 GHz with the Intel 945GME Express chipset, the GE V7768-322001 delivers robust computing power for embedded industrial, defense, and automation applications. It features up to 2 GB DDR2 SDRAM, dual Gigabit Ethernet ports on the front panel, extensive I/O including USB, SATA, serial ports, VGA, and a PCI-X PMC expansion site with EasyRail mounting for simplified PMC installation. The GE V7768-322001 supports VME64 modes via the Tundra Universe II interface and is ideal for real-time control, data acquisition, simulation, and mission-critical systems requiring high reliability and I/O flexibility. Its convection-cooled design and optional extended temperature operation make the GE V7768-322001 suitable for rugged environments. Although a legacy product, the GE V7768-322001 remains widely used in sustaining VME-based systems in power generation, transportation, and industrial automation. Engineers continue to rely on the GE V7768-322001 for its proven performance and compatibility with Windows, VxWorks, and Linux operating systems.

Model,GE V7768-322001

Manufacturer,GE Fanuc Intelligent Platforms (Abaco Systems)

Series,V7768 VME Single Board Computer

Product Type,6U VMEbus Dual-Slot SBC

Processor,Intel Core 2 Duo up to 2.16 GHz (4 MB L2 cache)

Chipset,Intel 945GME Express

System / Memory Bus,667 MHz

Memory,Up to 2 GB DDR2 SDRAM via single SODIMM

Storage,Up to 8 GB bootable CompactFlash (via secondary IDE)

Ethernet,"Dual Gigabit Ethernet (Intel 82571, front panel RJ45)"

USB,"4 × USB 2.0 (2 front, 2 rear via P2)"

Serial Ports,"2 × 16550-compatible (COM1 front DB-9, COM2 via P2)"

Graphics,VGA on front panel

Expansion,1 × 133 MHz PCI-X PMC site; supports PMC237CM1/V for additional sites

VMEbus Interface,"Tundra Universe II (VME64, A32/A24/D32/MBLT64 etc.)"

Other I/O,"2 × SATA, PS/2 keyboard/mouse, front panel options"

Power Requirements,+5 VDC primary (±5%); low power on ±12 VDC

Operating Temperature,0°C to +55°C (Core 2 Duo); extended options available

Cooling,Forced air (min. 400 LFM recommended)

Form Factor,"6U VME, dual-slot (4HP width)"

Applications,"Industrial automation, real-time control, simulation, defense, VME legacy systems"

Install the GE V7768-322001 into a compatible 6U VME chassis slot, ensuring proper alignment with J1 and J2 backplane connectors.

Secure the board and any attached PMC modules using the EasyRail system for top-side access.

Connect front-panel I/O (Gigabit Ethernet, VGA, USB, COM1, keyboard/mouse) and rear P2 signals as required.

Insert CompactFlash card if used for boot/storage and configure BIOS settings for boot device priority.

Apply VME chassis power and monitor front-panel LEDs or serial console for POST and BIOS initialization.

Load the operating system (Windows, VxWorks, or Linux) and install drivers for Ethernet, PMC, and VME interfaces.

Verify system performance, network connectivity, and PMC device recognition through diagnostic tools or application software.

Power down the VME chassis completely before inserting or removing the GE V7768-322001 to prevent backplane damage or electrical hazards.

Use ESD protection (wrist strap and grounded mat) when handling the board to safeguard the processor and SDRAM.

Ensure adequate forced-air cooling (minimum 400 LFM at heatsink) and do not exceed the 0–55°C operating temperature range for the Core 2 Duo variant.

Confirm VME backplane compatibility (VME64 support) and avoid mixing with incompatible bus masters.

Route Ethernet and signal cables away from high-voltage lines; use shielded cables for best signal integrity.

Verify PMC module alignment and secure mounting before powering on; check jumper/switch settings per the specific configuration.

After installation, run BIOS setup, perform memory and VME diagnostics, and clear any error logs before loading the application.

Monitor front-panel LEDs and system console daily on the GE V7768-322001 for boot status, Ethernet link/activity, or fault indications.

Check chassis temperature, fan operation, and airflow to maintain proper cooling around the processor and heatsink.

Review operating system logs and VME diagnostics for memory errors, bus issues, or network packet loss.

Inspect Ethernet cables, PMC connections, and front-panel connectors weekly for looseness or damage.

Clean dust from heatsinks, vents, and PMC area (power off) using compressed air every 1–3 months depending on environment.

Periodically verify CompactFlash integrity, backup critical configurations, and test PMC device functionality.

Execute full system diagnostics (CPU, memory, Ethernet, VME bus) quarterly and update BIOS/firmware only during planned maintenance.
