The GE MIFIIPI55E10HI00 is a robust Multilin MiF II Digital Feeder Management Relay from GE’s Multilin series, designed for comprehensive protection, control, monitoring, and metering of electrical distribution feeders. As a microprocessor-based numerical relay, the GE MIFIIPI55E10HI00 provides advanced overcurrent, directional, and ground fault protection along with breaker control and event recording capabilities.

The GE MIFIIPI55E10HI00 is widely deployed in medium-voltage distribution systems, industrial power networks, and utility substations to safeguard feeders against faults while ensuring reliable operation and fast fault clearing. Its flexible configuration, multiple protection elements, and communication options make the GE MIFIIPI55E10HI00 an ideal solution for both new installations and retrofit applications in demanding power system environments.

Model,GE MIFIIPI55E10HI00 (MiF II series)

Module Type,Digital Feeder Management Relay / Feeder Protection Relay

Protection Functions,"Phase & ground overcurrent (50/51), directional (67), ground fault (50N/51N), breaker failure, autoreclose, and more"

Current Inputs,5 A nominal (configurable CT inputs)

Voltage Inputs,Optional VT inputs for voltage-based elements

Power Supply,HI range: 125–250 V DC / 120–240 V AC

Digital Inputs / Outputs,Multiple programmable contact inputs & outputs

Communication,"RS485 (Modbus RTU), optional Ethernet or other protocols"

Display,Front-panel LCD with keypad for local programming

Operating Temperature,-20°C to +70°C

Humidity,"5% to 95% RH, non-condensing"

Dimensions,Approx. 105 mm × 75 mm × 140 mm (compact draw-out case)

Weight,Approx. 0.42–0.45 kg

Mounting,Panel or rack mount (draw-out chassis)

Compatibility,"Medium-voltage distribution feeders, industrial substations"

Operating the GE MIFIIPI55E10HI00 follows standard Multilin relay procedures:

Apply the correct control power (HI range: 125–250 V DC or 120–240 V AC) to the relay and verify the front-panel display powers up.

Enter the relay settings via the front keypad or EnerVista software and download the configuration file specific to the feeder application for the GE MIFIIPI55E10HI00.

Perform commissioning tests including injection of secondary currents/voltages to verify pickup levels, timing curves, and trip outputs of the GE MIFIIPI55E10HI00.

Monitor real-time metering values (currents, voltages, power, frequency) and protection element status through the HMI or SCADA system.

During normal operation, the GE MIFIIPI55E10HI00 continuously supervises the feeder and issues trip commands upon detection of faults.

In the event of a trip or alarm, review event records, oscillography, and fault reports stored in the GE MIFIIPI55E10HI00 for post-event analysis.

Periodically check self-diagnostic status and communication links to ensure continuous healthy operation of the GE MIFIIPI55E10HI00.

Safe installation of the GE MIFIIPI55E10HI00 is critical for protection reliability. Always isolate the feeder and apply lockout/tagout procedures before inserting or removing the relay. Use the draw-out chassis design: withdraw the unit carefully from the case. Connect CT and VT secondary circuits with proper polarity and short CT secondaries when the relay is removed. Wire control power, digital I/O, and communication ports (RS485) according to the wiring diagram, ensuring correct torque on terminal screws. Ground the relay case properly to minimize noise and ensure personnel safety. After installing the GE MIFIIPI55E10HI00, perform insulation resistance tests, secondary injection testing, and functional verification of all protection elements before placing the feeder in service. Only qualified protection engineers or technicians trained on GE Multilin relays should install or service the GE MIFIIPI55E10HI00.

Routine maintenance keeps the GE MIFIIPI55E10HI00 operating at peak reliability:

Visually inspect the front panel of the GE MIFIIPI55E10HI00 for alarm LEDs, display functionality, and any dust accumulation.

Review event logs, fault reports, and self-test diagnostics daily via the relay HMI or connected software.

Verify communication status (RS485 or Ethernet) and ensure no loss of data to the SCADA system.

Check control power supply voltage remains within the HI range specification.

Monitor operating temperature and ensure the relay environment stays within -20°C to +70°C.

Test trip and alarm contacts periodically during planned outages to confirm output functionality of the GE MIFIIPI55E10HI00.

Record any anomalies and schedule firmware updates or full calibration every 1–2 years (or per utility policy) to sustain the accuracy and dependability of the GE MIFIIPI55E10HI00.
