The GE IC754VGL06CTD ES0622 delivers crisp 640x480 VGA resolution with 64K colors for intuitive operator interaction in factory automation. Equipped with dual Ethernet ports and serial connectivity, the GE IC754VGL06CTD integrates seamlessly with VersaMax, Series 90-30, and PACSystems PLCs. Its compact NEMA 4/12 design and robust touchscreen make the GE IC754VGL06CTD ES0622 perfect for harsh manufacturing environments requiring reliable HMI performance.

Model GE IC754VGL06CTD ES0622 6" VersaView Touchscreen HMI

Display 6" TFT Color VGA 640x480 64K colors, anti-glare surface

Touchscreen Analog resistive, 5-wire 1024x1024 resolution mapping

Ethernet Ports 2x 10/100BaseT SRTP/SNPX, Modbus TCP

Serial Ports 1x RS-232, 1x RS-485 Printer/programming ports

Memory 8 MB Flash, 512K RAM Application storage

Power Supply 24 VDC ±20% 25W maximum consumption

Operating Temp 0°C to 55°C Front panel rated NEMA 4/12

Dimensions 235 x 178 x 62 mm Panel mount thickness

Software QuickDesigner v2.61+ CIMPLICITY configuration

Cut panel opening per GE IC754VGL06CTD ES0622 template (223 x 162 mm).

Insert GE IC754VGL06CTD from front and secure with mounting clamps.

Connect 24 VDC power to GE IC754VGL06CTD ES0622 rear terminals.

Wire Ethernet and serial cables to GE IC754VGL06CTD I/O connectors.

Download HMI application using QuickDesigner via Ethernet to GE IC754VGL06CTD.

Verify GE IC754VGL06CTD ES0622 startup screen and touch calibration.

Maintain 75mm behind-panel clearance for GE IC754VGL06CTD ventilation.

Use shielded CAT5 cables for GE IC754VGL06CTD ES0622 Ethernet in noisy areas.

Apply gasket seal properly around GE IC754VGL06CTD for NEMA rating.

Separate GE IC754VGL06CTD ES0622 power wiring from high-voltage circuits.

Clean GE IC754VGL06CTD touchscreen with approved anti-static cloth weekly.

Check GE IC754VGL06CTD ES0622 Ethernet link LEDs during operator shifts.

Archive HMI applications from GE IC754VGL06CTD quarterly to PC server.

Verify GE IC754VGL06CTD touchscreen calibration annually.

Update GE IC754VGL06CTD ES0622 firmware during scheduled maintenance outages.2026-03-24
