The GE IC698CPE030-HN is a high-performance Central Processing Unit (CPU) in the PACSystems RX7i series from GE Fanuc (now Emerson Automation). Powered by a 600 MHz Pentium-M processor, the GE IC698CPE030-HN delivers robust real-time control for complex machines, processes, and material handling systems. It features 64 MB of user memory, 64 MB of non-volatile flash storage, and an embedded 10/100 Mbps Ethernet interface, making the GE IC698CPE030-HN ideal for large-scale automation with high I/O counts and demanding logic requirements. The GE IC698CPE030-HN supports floating-point math, extensive communication protocols, and seamless integration with VME64 backplanes and a wide range of RX7i I/O modules. With three isolated serial ports and advanced diagnostics, the GE IC698CPE030-HN ensures reliable operation in industrial environments such as power generation, manufacturing, and process industries. Although a legacy model, the GE IC698CPE030-HN continues to provide dependable performance for sustaining or upgrading existing RX7i PACSystems installations.

Model,GE IC698CPE030-HN

Manufacturer,GE Fanuc Automation (Emerson Automation)

Series,PACSystems RX7i

Product Type,CPU Module (600 MHz Pentium-M)

Processor Speed,600 MHz

User Memory,64 MB battery-backed RAM

Flash Memory,64 MB non-volatile user flash

Floating Point Support,Yes

Ethernet Interface,"Embedded 10/100 Mbps (RJ45, auto-sensing)"

Serial Ports,"3 isolated: RS-232, RS-485, and RS-232 Station Manager"

Serial Protocols,"Modbus RTU Slave, SNP, Serial I/O"

I/O Capacity,"32K bits discrete I/O, 32K words analog I/O"

Ethernet Protocols,"SRTP, Modbus TCP/IP, EGD, Web Server, FTP"

Power Requirements,3.4 A @ 5 VDC (nominal from backplane)

Operating Temperature,0°C to 60°C (fan tray recommended for higher loads)

Mounting,Single slot in RX7i VME64 backplane

Additional Features,"Battery-backed real-time clock, extensive diagnostics, WinLoader support"

Install the GE IC698CPE030-HN into an available slot in the RX7i rack, ensuring proper alignment with the VME backplane.

Connect the Ethernet cable to the 10/100 RJ45 port and any required serial cables to the RS-232/RS-485 ports.

Apply power to the RX7i system and observe the front-panel LEDs for boot sequence and status (RUN, OK, etc.).

Connect a programming computer running Proficy Machine Edition (or compatible software) via Ethernet or serial port.

Configure hardware settings, assign IP address, and download the application program to the GE IC698CPE030-HN.

Verify I/O mapping, set the CPU to RUN mode, and monitor real-time variables and diagnostics.

Perform system tests to confirm logic execution, communication, and process control performance.

Power down the entire RX7i rack before inserting or removing the GE IC698CPE030-HN to avoid backplane damage or electrical hazards.

Use proper ESD protection (wrist strap and grounded workstation) when handling the module to prevent static damage to the Pentium-M processor.

Confirm the backplane is VME64 compatible and that the power supply can support the 3.4 A @ 5 VDC requirement along with other modules.

Route Ethernet and serial cables away from high-voltage or noisy lines; use shielded cables for best signal integrity.

Install a fan tray if the rack operates near the upper temperature limit or contains multiple high-power modules.

Verify battery installation (for memory retention) and check all connectors for secure seating before powering on.

After installation, run initial diagnostics and clear any fault tables prior to placing the system in operation.

Monitor the front-panel LEDs on the GE IC698CPE030-HN daily for RUN, OK, FAULT, BATTERY, and Ethernet link/activity status.

Check system diagnostics, fault tables, and scan times via programming software or HMI for any anomalies or communication errors.

Inspect rack temperature and ensure adequate ventilation or fan operation to maintain 0–60°C ambient conditions.

Review event logs and Ethernet statistics periodically for packet errors, connection drops, or memory usage warnings.

Clean dust from the module vents and backplane (with power off) using compressed air every 1–3 months depending on environment.

Verify battery voltage and replace as needed to protect user memory and real-time clock during power interruptions.

Perform scheduled backups of the application program and configuration; test CPU response and failover (if redundant setup) during maintenance windows.
