The GE IC695CPE330 is a high-performance CPU module in Emerson's (formerly GE Fanuc/GE Intelligent Platforms) PACSystems RX3i series, serving as a powerful programmable automation controller for demanding industrial applications. Equipped with a 1 GHz dual-core microprocessor and 64 Mbytes of built-in user memory, the GE IC695CPE330 supports large-scale logic, data-intensive processing, and advanced networking. It features two independent Gigabit Ethernet ports for high-speed communication, embedded PROFINET support, and compatibility with redundancy setups like Hot Standby and PROFINET System Redundancy (PNSR). The GE IC695CPE330 excels in process control, discrete manufacturing, motion, and IIoT-enabled systems, offering protocols such as SRTP, Modbus TCP, OPC UA, and EGD. Programmable via Proficy Machine Edition (PME), the GE IC695CPE330 handles up to 32K I/O points and integrates seamlessly with RX3i I/O, motion, and intelligent modules. Its robust design, optional Energy Pack for bumpless power failure handling, and field-upgradeable firmware make the GE IC695CPE330 a reliable choice for modern and legacy upgrades in automation environments.

Model,GE IC695CPE330

Manufacturer,GE Intelligent Platforms / Emerson Automation

Series,PACSystems RX3i

Product Type,CPU Module (1 GHz Dual-Core)

Processor,1 GHz dual-core microprocessor

User Memory,64 Mbytes (configurable for data and program)

Floating Point Support,Yes

Ethernet Interfaces,"2 independent ports (LAN1 & LAN2), 10/100/1000 Mbps"

Ethernet Protocols,"SRTP Client/Server, Modbus TCP/IP, OPC UA, EGD, PROFINET, DNP3 Outstation, IEC-61850 Client, IEC-104 Server, HART passthrough"

Serial Protocols,"Modbus RTU Slave, SNP Slave"

I/O Capacity,Up to 32K points (discrete + analog)

Redundancy Support,"Hot Standby, PROFINET System Redundancy (PNSR), MRP"

Energy Pack,Optional (IC695ACC402 for non-volatile memory retention)

Operating Temperature,0°C to 60°C (optional low-temp variants -40°C to 60°C)

Mounting,Occupies two slots in RX3i universal backplane

Additional Features,"Embedded PROFINET Controller, CFast memory card slot, field-upgradeable firmware"

Install the GE IC695CPE330 into a compatible double-slot position in the RX3i universal backplane (typically left-most or right of power supply).

Connect power supply module and apply 24 VDC or AC power to the rack.

Attach Ethernet cables to LAN1 (primary programming) and LAN2 (networking/I/O) ports as required.

If using Energy Pack, mount IC695ACC402 nearby and connect the interconnect cable securely.

Power up the system and observe LEDs for boot sequence (RUN, OUTPUTS ENABLED, etc.).

Connect a PC running Proficy Machine Edition (PME) via Ethernet to configure hardware, load logic, and set IP addresses.

Download the application program, validate I/O mapping, and initiate RUN mode for process control or monitoring.

Power off the RX3i rack completely before inserting or removing the GE IC695CPE330 to avoid backplane damage or electrical hazards.

Use ESD protection (wrist strap, grounded mat) when handling the module to prevent static damage to the processor or memory.

Ensure the backplane slot pair is CPU-compatible (refer to RX3i System Manual GFK-2314); double-slot occupancy required.

Verify power supply compatibility (e.g., IC695PSA040H or later for lightly loaded racks) and stable voltage input.

Route Ethernet cables away from high-voltage lines; use shielded Cat5e/Cat6 for noise immunity and Gigabit performance.

If Energy Pack is used, follow grounding and cable routing guidelines to prevent data loss during power dips.

After installation, perform initial diagnostics via PME to confirm no faults, check firmware version, and clear any startup errors.

Monitor front-panel LEDs on the GE IC695CPE330 daily for RUN, OK, FAULT, BATTERY, and Ethernet link/activity status.

Check system diagnostics in PME or HMI for alarms, scan times, memory usage, or communication errors.

Inspect rack temperature and ventilation to maintain 0–60°C ambient; ensure fans are operational if present.

Review event logs and fault tables for early detection of I/O issues, network drops, or redundancy sync problems.

Clean dust from module vents and backplane (power off) using compressed air every 1–3 months based on environment.

Periodically verify firmware version and apply updates from Emerson support if needed (use official upgrade kits).

Test backup/restore procedures, Energy Pack charge status (if installed), and redundancy failover during scheduled maintenance.
