The GEDL-1200 RTU is a highly reliable remote terminal unit designed for industrial and utility automation systems. Its robust performance, modular structure, and versatile communication functions make it suitable for power distribution, oil and gas pipelines, and environmental monitoring. The GE DL-1200 RTU provides precise data acquisition and remote control with excellent stability even in harsh environments.

The advanced configuration tools of the GE DL-1200 RTU allow easy integration with SCADA systems, ensuring seamless connectivity and efficient data management. This model’s flexible architecture supports multiple I/O expansions, making the GE DL-1200 RTU a long-term, scalable solution for modern automation networks.

Model GEDL-1200 RTU

CPU 32-bit industrial-grade processor

Memory 256 MB RAM, 512 MB Flash

Operating Voltage DC 24V (range 19–30V)

Communication Ports 2× RS485, 1× Ethernet, 1× USB

Protocol Support Modbus RTU/TCP, DNP3, IEC 60870-5-104

Operating Temperature -40°C to +70°C

Dimensions 210 × 145 × 55 mm

IP Protection IP65

Weight 1.8 kg

Power on the GE DL-1200 RTU and verify LED indicators are functioning.

Connect the unit to the communication network and configure IP settings.

Use the GE configuration software to load control logic and I/O mapping.

Test input and output channels for correct response.

Connect the GE DL-1200 RTU to the supervisory control system (SCADA).

Monitor communication status and verify data accuracy.

Mount the GE DL-1200 RTU on a stable, vibration-free surface.

Ensure proper grounding to prevent static discharge.

Avoid exposure to direct sunlight or water leakage.

Maintain clearance for ventilation and cable routing.

Use shielded communication cables for long-distance connections.

Inspect the GE DL-1200 RTU periodically for loose wiring or corrosion.

Clean external surfaces with a dry, non-abrasive cloth.

Check power supply voltage and communication ports regularly.

Update firmware through the manufacturer’s maintenance software.

Record performance data and system logs monthly for trend analysis.
