In modular control and embedded computing systems, the GE VME-PMC-CADDY is commonly used to add PMC-based I/O, communication, or processing functions to an existing VME chassis without redesigning the whole platform. The GE VME-PMC-CADDY supports master or slave operation on the VMEbus, which makes it suitable for high-bandwidth, multi-board architectures in industrial automation, testing, and aerospace-style embedded platforms.

Model GE VME-PMC-CADDY

Product type VME64 carrier board for PMC modules

PMC capacity 2 single-width PMC modules or 1 double-width module

VME bridge Tundra Universe II CA91C142

VME interface A32/D32, up to 32 address signals, 4-level arbiter

PCI side 33 MHz PCI connection

Rear I/O PMC I/O routed to VME P2 connector

Operating mode Master or slave on the VMEbus

Design focus Low power, easy cooling, industrial use

Standards IEEE P1386 / IEEE 1014 Rev. D

Prepare the VME chassis and confirm the slot is available for the GE VME-PMC-CADDY.

Install the PMC module or modules onto the GE VME-PMC-CADDY before mounting the carrier board.

Insert the GE VME-PMC-CADDY into the VME slot and secure it with the front panel screws.

Connect the external field wiring through the rear I/O / P2 arrangement as required by the PMC design.

Power up the system and verify that the GE VME-PMC-CADDY is recognized correctly by the VME controller.

Verify the PMC module pinout before installation, because the GE VME-PMC-CADDY supports defined P2 routing options.

Make sure the chassis cooling and airflow are sufficient for the GE VME-PMC-CADDY and its PMC modules.

Use ESD protection when handling the GE VME-PMC-CADDY and any attached PMC cards.

Confirm that the VME bus settings match the role of the GE VME-PMC-CADDY as master or slave.

Check that the slot and backplane are compatible with the GE VME-PMC-CADDY form factor before insertion.

Periodically inspect the edge connectors of the GE VME-PMC-CADDY for dust, oxidation, or bent contacts.

Check fastening screws and board seating during scheduled shutdowns.

Verify the connected PMC modules remain firmly mounted on the GE VME-PMC-CADDY.

Monitor temperature and airflow inside the chassis to keep the GE VME-PMC-CADDY stable in long-term operation.

Back up system configuration data before replacing or moving the GE VME-PMC-CADDY.
