The GE IC693PWR322F is a 24/48 VDC standard power supply designed for GE Fanuc IC693 PLC racks, serving as the main DC power source for backplane and I/O staging. The GE IC693PWR322F can operate at a nominal 24 or 48 VDC input, with a wide input range (typically about 18–60 VDC), so the GE IC693PWR322F adapts well to different DC-supply conditions in industrial sites.

The GE IC693PWR322F outputs three separate DC rails: a +5 VDC output for the backplane, a +24 VDC relay output for Series 90-30 relay-output modules, and a +24 VDC isolated output for input modules and some special I/O. The GE IC693PWR322F includes overcurrent, short-circuit, and overheating protection, helping to improve system uptime and reduce risk of damage to the PLC rack.

Model GE IC693PWR322F

Series GE Fanuc IC693 / Series 90-30 PLC

Power rating 30 W total output capacity

Input voltage 24/48 VDC nominal; input range typically 18–60 VDC

Output 1 +5 VDC for backplane power (current limited to several amps depending on build)

Output 2 +24 VDC relay output for Series 90-30 relay-output modules

Output 3 +24 VDC isolated output for 24 VDC input modules and external I/O power

Operating temperature 0–60 °C, industrial-grade cabinet use

LED indicators Power-OK LED showing normal operation; goes off on fault or low input

Typical applications GE Series 90-30 PLC racks in manufacturing, utilities, and processcontrol systems

Install the GE IC693PWR322F into the standard Series 90-30 power-supply slot on the IC693 baseplate, making sure it is fully seated and mechanically secured.

Connect the 24/48 VDC DC power source to the GE IC693PWR322F’s input terminals with proper polarity and ensure the cabinet is grounded.

Verify that the Power/OK LED on the GE IC693PWR322F turns green when power is applied, indicating normal operation and stable outputs.

Connect the +5 VDC backplane output, +24 VDC relay output, and +24 VDC isolated output to the corresponding PLC modules (CPU, relay outputs, input modules) as specified in the rack wiring diagram.

Power on the system under light load and confirm that the GE IC693PWR322F does not shut down due to overload or short circuit before energizing all field devices.

Always verify the DC input voltage and polarity before energizing the GE IC693PWR322F; incorrect wiring or reversed polarity can damage the module.

Mount the GE IC693PWR322F in a clean, ventilated cabinet within the 0–60 °C operating range to avoid overheating and premature aging.

Use appropriately sized wires and fuses on the DC input line to the GE IC693PWR322F and avoid short-circuiting the output terminals while the supply is powered.

Do not exceed the 30 W total load capacity of the GE IC693PWR322F; calculate the sum of backplane, relay-output, and input-module power before adding more I/O.

Regularly inspect the GE IC693PWR322F LED status; if the Power/OK LED flickers or goes out, investigate input voltage drops or overloads.

Periodically check the DC input and output voltages with a multimeter and compare them to the expected values to detect early-stage power-supply drift.

Clean ventilation slots around the GE IC693PWR322F and keep the surrounding area free of dust and moisture to maintain cooling and prevent insulation issues.

If the GE IC693PWR322F repeatedly shuts down or trips, review the connected load and verify there are no shorted wiring runs or saturated input modules.
