The GE 239 (GE Multilin 239 Motor Protection Relay) is a compact, microprocessor-based digital motor protection relay designed to provide comprehensive protection and monitoring for small to medium-sized three-phase AC induction motors and associated mechanical equipment. The GE 239 fully protects motors against thermal overload, short circuit, ground fault, current unbalance, mechanical jam, undercurrent, and overtemperature conditions using a sophisticated thermal model with 15 selectable overload curves. Optional RTD inputs (239-RTD variants) enable direct stator and bearing temperature monitoring, while analog output options (239-AN) support process integration. With Modbus RTU communication, a bright LED display, and simple front-panel programming, the GE 239 is widely deployed in industrial plants, utilities, pumping stations, fans, compressors, and conveyor systems. Although manufacturing of the GE 239 has been discontinued (legacy product with recommended migration to 339, 859, or 869 relays), it remains a reliable and popular choice for sustaining existing motor control centers (MCCs) due to its proven durability, ease of use, and cost-effective protection. The GE 239 helps prevent costly motor damage, reduces downtime, and provides valuable diagnostic data for maintenance teams.

Model,GE 239 (Multilin 239 Motor Protection Relay)

Manufacturer,GE Multilin (GE Vernova)

Series,239 Motor Protection Relay

Product Type,Digital Motor Protection Relay

Phase CT Inputs,1 A or 5 A secondary (programmable)

Control Power,85–265 VAC / 95–300 VDC (standard)

Thermal Model,Separate start/run overload curves (15 fixed shapes)

Protection Elements,"Thermal overload, short circuit, ground fault, current unbalance, mechanical jam, undercurrent, locked rotor, breaker failure, overtemperature (thermistor/RTD option)"

RTD Inputs (optional),Up to 3 or more (stator/bearing/ambient)

Analog Outputs (optional),4–20 mA (AN variant)

Communications,RS485 Modbus RTU

Outputs,"Trip, Alarm, Auxiliary relays"

Display,LED indicators + alphanumeric display

Operating Temperature,-20°C to +60°C (typical)

Mounting,Panel or DIN rail mount

Applications,"Low/medium voltage motors, pumps, fans, compressors, conveyors"

Mount the GE 239 in the motor control panel or MCC and connect control power (85–265 VAC or 95–300 VDC).

Wire phase CTs (and ground CT if used) with correct polarity; install shorting blocks during commissioning.

Connect RTDs (if equipped), thermistor, and output relays to the motor starter/contactor circuit.

Program motor data (FLC, service factor, CT ratio, overload curve, etc.) using the front-panel keypad or EnerVista/239 Setup software.

Power up and verify the “In Service” LED; review actual values for phase currents, thermal capacity, and status.

Start the motor and monitor thermal capacity used, unbalance, and any alarms during operation.

Use the event recorder and diagnostic features to review trips or pre-trip data after any fault condition.

De-energize all motor and control circuits before wiring or installing the GE 239 to avoid electrical hazards.

Use proper ESD protection when handling the relay.

Never leave CT secondaries open-circuited; always use shorting blocks during installation or testing.

Verify control power matches the relay rating and install appropriate fusing (typically 2.5 A slow-blow).

Route RS485 communication cables as shielded twisted-pair with proper termination (120 Ω).

Separate low-level signal wiring (CTs, RTDs) from high-voltage power cables to minimize noise.

After wiring, perform secondary injection testing on CT inputs and functional testing of relays before energizing the motor.

Observe the front-panel LEDs and display daily on the GE 239 for “In Service”, trip, alarm, or any active fault indications.

Monitor actual values (phase currents, thermal capacity used, unbalance, ground current) for abnormal trends.

Check and acknowledge any pending alarms or trips via the keypad; review the event recorder for recent operations.

Inspect external wiring, CT connections, and terminal tightness weekly for corrosion or looseness in the MCC environment.

Verify RTD readings (if equipped) and compare with expected motor temperatures.

Clean the front panel and vents (relay powered off or in test mode) with a soft cloth or low-pressure air every 1–3 months.

During scheduled maintenance, test protection elements using simulation mode, force output relays, review statistics (starts, running hours), and backup settings via software.
