The ABB PFTL101A 2.0KN 3BSE004172R1 is a high-performance force transducer designed for precise tension measurement and process control in industrial automation. Engineered for reliability and accuracy, the ABB PFTL101A 2.0KN 3BSE004172R1 ensures stable performance in demanding production environments such as paper machines, rolling mills, and web tension systems. This sensor converts mechanical force into a precise electrical signal, enabling consistent load monitoring.

Model ABB PFTL101A 2.0KN 3BSE004172R1

Rated Load 2.0 kN

Measurement Type Force / Tension

Output Signal mV/V analog (typical)

Sensitivity High precision, stable output

Overload Capacity Up to 150% of rated load

Operating Temperature -10°C to +70°C

Protection Class IP65 (dust and water resistant)

Material Stainless steel housing

Connection Standard 4-wire or 6-wire configuration

Mounting the transducer:

Secure the ABB PFTL101A 2.0KN 3BSE004172R1 on a rigid, vibration-free surface to ensure accurate readings.

Alignment:

Align the load direction parallel to the transducer’s sensing axis. Avoid side loading or twisting.

Electrical wiring:

Connect the output cables according to ABB’s standard wiring diagram, maintaining shielded cable integrity.

Calibration:

Perform a zero-load calibration before full operation to ensure the ABB PFTL101A 2.0KN 3BSE004172R1 reads correctly.

Signal testing:

Verify stable signal output under known loads to confirm correct installation.

Avoid exposing the ABB PFTL101A 2.0KN 3BSE004172R1 to excessive vibration or mechanical shock.

Keep all mounting surfaces clean and free of oil.

Do not exceed the rated load (2.0 kN).

Use proper grounding to reduce electrical noise interference.

Ensure the sensor cable is protected from physical damage and moisture.

Inspect mounting bolts and hardware regularly to ensure the ABB PFTL101A 2.0KN 3BSE004172R1 remains firmly in place.

Clean the sensor housing with a dry, lint-free cloth—avoid solvents or corrosive cleaners.

Check signal cables periodically for damage or wear.

Recalibrate the ABB PFTL101A 2.0KN 3BSE004172R1 at scheduled service intervals (recommended every 6–12 months).

Replace any worn components or connectors immediately to maintain measurement accuracy.
