The ABB CP651-WEB is an advanced 10.4-inch HMI control panel from the CP600 series, featuring a TFT touchscreen and integrated microbrowser for web-based visualization with ABB AC500 systems.

Model CP651-WEB

Product ID 1SAP551200R0001

Display 10.4" TFT-LCD, 800×600 pixels, 64K colors, 300 cd/m²

Touchscreen Single-touch resistive, 4-wire

Power Supply 24 V DC (18-30 V), 24 W max

Interfaces 2× Ethernet 10/100 MBit, RS232/422/485, 2× USB 2.0, SD slot

Memory 256 MB RAM (program), 256 MB Flash (data)

Operating Temp 0°C to +50°C (storage -20°C to +70°C)

Protection Front IP66, rear IP20

Dimensions 287×232×60 mm (2.1 kg)

Panel preparation

Cut panel opening to 276×221 mm for the ABB CP651-WEB and ensure door thickness 2-6 mm.

Mounting

Insert ABB CP651-WEB from front, secure with clamps from rear for IP66 seal.

Wiring

Connect 24 V DC power and Ethernet/RS232/USB cables to ABB CP651-WEB rear terminals.

Configuration

Load HMI project via Panel Builder 600 or web server setup for ABB CP651-WEB.

Testing

Verify touchscreen response and network connectivity on ABB CP651-WEB.

Maintain panel flatness for ABB CP651-WEB gasket seal integrity.

Fuse 24 V DC supply feeding ABB CP651-WEB at 2 A max.

Ground Ethernet shields near ABB CP651-WEB for EMC compliance.

Avoid direct sunlight on ABB CP651-WEB display.

Use ESD protection when accessing ABB CP651-WEB ports.

Clean ABB CP651-WEB screen with microfiber cloth monthly.

Check mounting clamps on ABB CP651-WEB quarterly.

Backup HMI projects from ABB CP651-WEB annually.

Test touchscreen calibration on ABB CP651-WEB yearly.

Replace ABB CP651-WEB battery after 3 years if clock drifts.
